| F200 |
F300 |
F400 |
F500 |
F750 |
F1000 |
F1500 |
F2000 |
F2500 |
F3000 |
F3500 |
F4000 |
F4500 |
|
| Filter Area, Sq. Feet | 17 |
23 |
26 |
29 |
35 |
45 |
55 |
72 |
89 |
110 |
129 |
147 |
165 |
| Filter Area, Sq. Meters | 1.58 |
2.14 |
2.4 |
2.7 |
3.3 |
4.2 |
5.1 |
6.7 |
8.3 |
10.2 |
12 |
13.7 |
15.3 |
| Length "A", Feet/ Inches | 12'-5" |
15'-2" |
16'-1" |
17'-4" |
19'-7" |
20'-8" |
23'-8" |
27'-8" |
32'-8" |
35'-6" |
40'-3" |
45'-0" |
49'-9" |
| Length "A", Meters | 3.8 |
4.6 |
4.9 |
5.3 |
6.0 |
6.3 |
7.2 |
8.4 |
10.0 |
10.8 |
12.3 |
13.7 |
15.2 |
| Width "B", Feet/ Inches | 4'-0" |
4'-0" |
5'-2" |
5'-2" |
5'-2" |
6'-2" |
6'-4" |
6'-4" |
6'-7" |
7'-4" |
7'-4" |
7'-6" |
7'-6" |
| Width "B", Meters | 1.2 |
1.2 |
1.6 |
1.6 |
1.6 |
1.88 |
1.93 |
1.93 |
2.0 |
2.24 |
2.24 |
2.3 |
2.3 |
| Height "C", Feet/ Inches | 4'-10" |
4'-10" |
6'-5" |
6'-5" |
6'-5" |
6'-8" |
6'-8" |
7'-4" |
7'-4" |
7'-7" |
7'-7" |
7'-7" |
7'-7" |
| Height "C", Meters | 1.5 |
1.5 |
1.9 |
1.9 |
1.9 |
2.0 |
2.0 |
2.23 |
2.23 |
2.3 |
2.3 |
2.3 |
2.3 |
| Water Leg "D", Inches | 28" |
28" |
42" |
42" |
42" |
78" |
78" |
78" |
78" |
78" |
78" |
78" |
78" |
| Water Leg "D", Meters | 0.71 |
0.71 |
1.1 |
1.1 |
1.1 |
1.42 |
1.42 |
1.42 |
1.42 |
1.42 |
1.42 |
1.42 |
1.42 |
| Exhauster Motor HP | 5 |
5 |
10 |
10 |
10 |
20 |
20 |
20 |
20 |
20 |
20 |
20 |
20 |
| Exhauster Motor KW | 3.73 |
3.73 |
7.46 |
7.46 |
7.46 |
14.91 |
14.91 |
14.91 |
14.91 |
14.91 |
14.91 |
14.91 |
14.91 |
| Weight, LBS. | 2,800 |
3,100 |
4,150 |
5,585 |
6,500 |
9,600 |
13,000 |
15,000 |
16,000 |
18,000 |
19,500 |
21,000 |
24,000 |
| Weight, KGS. | 1,270 |
1,400 |
1,880 |
2,530 |
2,950 |
4,360 |
5,900 |
6,800 |
7,270 |
8,180 |
8,860 |
9,500 |
10,900 |
| W75 |
W90 |
W120 |
W148 |
W162 |
W190 |
W215 |
W250 |
|
| Filter Area, Sq. Feet | 75 |
90 |
120 |
148 |
162 |
190 |
215 |
250 |
| Filter Area, Sq. Meters | 7.0 |
8.4 |
11.0 |
13.7 |
15.0 |
17.6 |
20.0 |
23.2 |
| Length "A", Feet/ Inches | 21'-9" |
24'-9" |
28'-9" |
33'-9" |
36'-1" |
40'-10" |
45'-7" |
50'-4" |
| Length "A", Meters | 6.6 |
7.5 |
8.8 |
10.3 |
11.0 |
12.4 |
13.9 |
15.3 |
| Width "B", Feet/ Inches | 8'-10" |
8'-10" |
9'-0" |
9'-0" |
9'-4" |
9'-4" |
9'-4" |
9'-4" |
| Width "B", Meters | 2.69 |
2.69 |
2.74 |
2.74 |
2.85 |
2.85 |
2.85 |
2.85 |
| Height "C", Feet/ Inches | 6'-11" |
6'-11" |
7'-6" |
7'-6" |
7'-8" |
7'-8" |
7'-8" |
7'-8" |
| Height "C", Meters | 2.1 |
2.1 |
2.3 |
2.3 |
2.34 |
2.34 |
2.34 |
2.34 |
| Water Leg "D", Inches | 78" |
78" |
78" |
78" |
78" |
78" |
78" |
78" |
| Water Leg "D", Meters | 1.42 |
1.42 |
1.42 |
1.42 |
1.42 |
1.42 |
1.42 |
1.42 |
| Exhauster Motor HP | 20 |
20 |
20 |
20 |
20 |
20 |
20 |
20 |
| Exhauster Motor KW | 14.91 |
14.91 |
14.91 |
14.91 |
14.91 |
14.91 |
14.91 |
14.91 |
| Weight, LBS. | 15,000 |
16,000 |
19,500 |
21,000 |
24,000 |
27,000 |
30,000 |
32,500 |
| Weight, KGS. | 6,800 |
7,275 |
8,865 |
9,550 |
10,900 |
12,300 |
13,600 |
14,800 |
| 8W110 |
8W130 |
8W160 |
8W200 |
8W220 |
8W255 |
8W290 |
8W330 |
|
| Filter Area, Sq. Feet | 110 |
130 |
160 |
200 |
220 |
255 |
290 |
330 |
| Filter Area, Sq. Meters | 10.22 |
12.08 |
14.86 |
18.58 |
20.44 |
23.69 |
26.94 |
30.66 |
| Length "A", Feet/ Inches | 21'-9" |
24'-9" |
28'-9" |
33'-9" |
36'-1" |
40'-10" |
45'-7" |
50'-4" |
| Length "A", Meters | 6.6 |
7.5 |
8.8 |
10.3 |
11.0 |
12.4 |
13.9 |
15.3 |
| Width "B", Feet/ Inches | 11'
2-1/4" |
11'
2-1/4" |
11'
2-1/4" |
11'-4-1/4" |
12'-2-3/4" |
12'-2-3/4" |
12'-2-3/4" |
12'-2-3/4" |
| Width "B", Meters | 3.41 |
3.41 |
3.41 |
3.46 |
3.73 |
3.73 |
3.73 |
3.73 |
| Height "C", Feet/ Inches | 6'-11" |
6'-11" |
7'-6" |
7'-6" |
7'-8" |
7'-8" |
7'-8" |
7'-8" |
| Height "C", Meters | 2.1 |
2.1 |
2.3 |
2.3 |
2.34 |
2.34 |
2.34 |
2.34 |
| Water Leg "D", Inches | 78" |
78" |
78" |
78" |
78" |
78" |
78" |
78" |
| Water Leg "D", Meters | 1.42 |
1.42 |
1.42 |
1.42 |
1.42 |
1.42 |
1.42 |
1.42 |
| Exhauster Motor HP | 20 |
20 |
20 |
20 |
20 |
20 |
20 |
20 |
| Exhauster Motor KW | 14.91 |
14.91 |
14.91 |
14.91 |
14.91 |
14.91 |
14.91 |
14.91 |
| Weight, LBS. | 20,000 |
21,000 |
26,000 |
28,000 |
32,000 |
36,000 |
40,000 |
42,000 |
| Weight, KGS. | 9,072 |
9,520 |
11,793 |
12,701 |
14,515 |
16,330 |
18,144 |
19,051 |
| F40 |
F60 |
F80 |
F120 |
F122 |
F124 |
F126 |
|
| Filter Area, Sq. Feet | 4.2 |
4.2 |
12 |
12 |
16.6 |
21 |
26 |
| Filter Area, Sq. Meters | 0.4 |
0.4 |
1.1 |
1.1 |
1.5 |
1.95 |
2.4 |
| Reservoir Capacity, US Gal. | 50 |
50 |
130 |
130 |
154 |
178 |
202 |
| Reservoir Capacity, Liters | 190 |
190 |
490 |
490 |
580 |
675 |
765 |
| Length "A", Feet/ Inches | 6'-8" |
6'-8" |
8'-7" |
8'-7" |
10'-7" |
12'-7" |
14'-7" |
| Length "A", Meters | 2.0 |
2.0 |
2.6 |
2.6 |
3.2 |
3.8 |
4.5 |
| Width "B", Feet/ Inches | 2'-8" |
2'-8" |
4'-2" |
4'-2" |
4'-2" |
4'-2" |
4'-2" |
| Width "B", Meters | 0.8 |
0.8 |
1.3 |
1.3 |
1.3 |
1.3 |
1.3 |
| Height "C", Feet/ Inches | 2'-11" |
2'-11" |
4'-4" |
4'-4" |
4'-4" |
4'-4" |
4'-4" |
| Height "C", Meters | 0.9 |
0.9 |
1.3 |
1.3 |
1.3 |
1.3 |
1.3 |
| Height to Distributor Top "D", Inches | 18" |
18" |
22-1/2" |
22-1/2" |
22-1/2" |
22-1/2" |
22-1/2" |
| Height to Distributor top "D", Meters | 0.46 |
0.46 |
0.572 |
0.572 |
0.572 |
0.572 |
0.572 |
| Exhauster Motor HP | 1 |
1-1/2 |
3 |
5 |
5 |
5 |
5 |
| Exhauster Motor KW | 0.746 |
1.12 |
2.24 |
3.73 |
3.73 |
3.73 |
3.73 |
| Weight, LBS. | 990 |
1,100 |
1,160 |
1,620 |
1,740 |
1,860 |
1,980 |
| Weight, KGS. | 450 |
500 |
527 |
735 |
790 |
845 |
900 |
